MIL-PRF-8516G
TABLE II. Electric properties of cured compound - Continued.
Property
Requirement 3/
Test
Cure A (4.7.1) Cure B (4.7.2)
paragraph
Insulation resistance, megohm, minimum,
4.9.3.7
after hydrolytic stability, electrical
Plastic inserts
4,000
Resilient inserts
4,000
High potential resistance
No breakdown
4.9.3.8
Air leakage, maximum/hour
1 cubic inch
4.9.3.9
Overload
Shall not
4.9.3.10
ignite
1/ The arc resistance shall be the number of seconds required to cause continuous burning
or the formation of a conducting path in the specimen, whichever occurs first.
2/ When unpotted connectors having an insulation resistance of 5,000 to 10,000 megohms
(as determined in 4.9.3.5) are used, the value 4,000 megohms, minimum, shall be
substituted for all insulation resistance values listed.
3/ Unless otherwise specified, the given value is for all types and classes. "" indicates no
requirement.
4. VERIFICATION
4.1 Classification of inspections. The inspection requirements specified herein are
classified as follows:
a. Qualification inspection (see 4.3).
b. Conformance inspection (see 4.4).
4.2 Inspection conditions. Unless otherwise specified, all inspections shall be performed in
accordance with the test conditions specified in the applicable test method or test paragraph in
this specification.
9
